Pipeline Management

The pipeline dashboard provides batch processing controls and status monitoring for extraction operations.

Pipeline Dashboard

Navigate to Tools > Pipeline Dashboard or direct URL: /pipeline/dashboard

Pipeline Dashboard

Dashboard Overview

The dashboard displays:

Section Content
Queue Status Pending, running, completed job counts
Recent Jobs Last 20 extraction jobs with status
Case Selection Cases available for batch processing
Controls Start, pause, cancel batch operations

Queue Management

Navigate to Tools > Queue Management or direct URL: /pipeline/queue

Queue Operations

Action Description
Start Batch Begin processing selected cases
Pause Suspend current processing
Resume Continue paused processing
Cancel Stop and clear queue

Job Status

Status Meaning
Pending Queued for processing
Running Currently extracting
Completed Successfully finished
Failed Error during extraction
Cancelled Manually stopped

Batch Processing

Starting a Batch

  1. Navigate to Pipeline Dashboard
  2. Select cases for processing
  3. Choose extraction steps to run
  4. Click Start Batch

Monitoring Progress

The dashboard updates in real-time showing:

  • Current case being processed
  • Step completion within each case
  • Overall batch progress percentage
  • Estimated time remaining

Error Handling

Failed jobs display:

  • Error message and stack trace
  • Case and step where failure occurred
  • Retry option for transient failures

Celery Integration

Pipeline processing uses Celery for background task management.

Worker Status

The dashboard shows Celery worker status:

Indicator Meaning
Green Workers active and healthy
Yellow Workers busy, queue growing
Red No workers available

Configuration

See Settings for Celery configuration options.
